Samsung OH55A-S — 55" OHA-S Series Outdoor Display, >3,500 Nit (LH55OHAOSGBXGO)
Sale price
$5,499.00
Regular price
$5,774.00
Skip to product information
Samsung OH55A-S — 55" OHA-S Series Outdoor Display, >3,500 Nit (LH55OHAOSGBXGO)
Sale price
$5,499.00
Regular price
$5,774.00
MPN · LH55OHAOSGBXGO
Samsung OH55A-S — 55" OHA-S Series All-In-One Outdoor Display, >3,500 Nit UL-Verified
Samsung's OH55A-S is the 55-inch all-in-one outdoor commercial display from the current OHA-S Series — UL-verified for outdoor visibility above 3,500 nits, with Magic Protection Glass anti-reflection bonded to the panel face and a hidden internal fan system that prevents humidity buildup without exposing intake or exhaust to the elements. Engineered for drive-thru menu lanes, gas station forecourts, transit hubs, stadium concourses, EV charging stations, and exterior wayfinding — wherever the panel has to survive direct weather and stay sharp in stadium-bowl sun.
>3,500 Nit UL-Verified
IP56 All-In-One
Magic Protection Glass
Hidden Fan Ventilation
24/7 Outdoor Duty
Samsung Warranty
Features that matter for the Samsung OH55A-S
>3,500 Nits — UL-Verified Outdoor Visibility
Third-party UL-verified, not just spec-sheet brightness. Stays readable in stadium-bowl sun, drive-thru lanes at noon, and reflective-canopy gas station forecourts.
IP56 All-In-One Weatherproof Cabinet
Single-piece sealed outdoor enclosure — no separate housing required. Rated against high-pressure water jets, dust, snow, and humidity.
Magic Protection Glass Anti-Reflection
Bonded anti-reflection treatment integrated into the panel face. More durable than retrofit anti-glare film, which can bubble or peel under direct sun and humidity.
Hidden Fan Ventilation
Humidity-prevention airflow without exposed intake/exhaust ports — the difference between standard and coastal-tolerant outdoor signage.
Heat-Resistant Outdoor Design
Engineered for full-sun, high-ambient-temperature, and humid coastal climates. Auto brightness sensor adapts to daylight and night-time levels.
24/7 Outdoor Duty + Samsung VXT
Always-on capable. Samsung VXT cloud CMS for fleet-level content scheduling, brightness automation, and uptime monitoring.
Spec snapshot
Screen Size55 inches
Resolution1,920 × 1,080 (Full HD)
Brightness>3,500 cd/m² (UL-verified)
Weather SealingIP56 all-in-one
Anti-ReflectionMagic Protection Glass
VentilationHidden internal fan
Operating Hours24 hrs/day, 7 days/wk
Auto BrightnessSensor-based
CMSSamsung VXT / MagicINFO
CabinetAll-in-one outdoor (no separate housing)
Full Spec Sheet — Samsung OH55A-S
Display
Screen Size55 inches
Panel TypeS-PVA LED (commercial outdoor)
Resolution1,920 × 1,080 (Full HD)
Aspect Ratio16:9
Brightness>3,500 cd/m² (UL-verified outdoor)
Contrast Ratio4000:1 (typ.)
Viewing Angle178° / 178° (H/V)
Anti-ReflectionMagic Protection Glass (bonded)
Auto BrightnessSensor-based daylight/night adjustment
Operating Hours24 hrs/day, 7 days/wk
OrientationLandscape only
Outdoor Protection
Weather SealingIP56 all-in-one sealed cabinet
Front GlassMagic Protection Glass — bonded anti-reflection
Cabinet ConstructionAll-in-one weatherproof — no separate housing required
Heat ManagementHidden internal fan ventilation (humidity-prevention airflow without exposed intake/exhaust)
Coastal ToleranceStandard cabinet handles light coastal exposure; severe salt-fog environments may require additional install guidance
Connectivity
HDMI2 (HDMI 2.0)
DisplayPort1 (DP 1.2)
USB1 (USB 2.0)
AudioAudio In, Audio Out, RJ45
RS232CYes (in/out)
CMS CompatibilitySamsung VXT, MagicINFO Server, BrightSign, Carousel Cloud
Physical
Dimensions (W × H × D)1,300 × 776 × 145 mm (51.2" × 30.6" × 5.7") approx.
Weight44.0 kg (97.0 lbs) approx.
VESA Mount400 × 400 mm (use UL-listed wind-load rated outdoor mount)
Cabinet ColorBlack
Power & Environment
Power SupplyAC 100–240V, 50/60Hz
Power Consumption (typ.)395W
Power Consumption (max)550W
Operating Temperature-30°C to 50°C (-22°F to 122°F)
Operating Humidity10% to 100% (sealed cabinet)
Storage Temperature-30°C to 60°C
Certifications & Warranty
Brightness CertificationUL-verified outdoor signage brightness
Safety / EMCFCC, UL
Commercial Warranty3 Year Samsung Commercial (outdoor — parts & labor, sealed cabinet must remain intact)
Wind Load / MountInstall must meet Samsung's outdoor wind-load and clearance specs
Where the OH55A-S fits
- Quick-service drive-thru lanes — outdoor menu boards with daypart-able content and POS-tied dynamic pricing.
- Gas station forecourts & convenience stores — fuel pricing, fountain promos, lottery results. Magic Protection Glass keeps content readable through canopy reflections.
- EV charging stations — sponsor advertising while drivers wait. Emerging high-margin advertising surface.
- Transit hubs (bus shelter, train platform, ferry terminal) — schedule info, sponsor inventory, weather alerts.
- Stadium concourses & outdoor concession stands — menu, beer wall, sponsor inventory readable in stadium sun.
- Building-mounted directory or wayfinding (covered exterior) — campus, hospital, government complex, corporate park exterior signage.
- Auto dealership outdoor lots — vehicle spotlights, financing offers, service department promotions.
Procurement FAQ
What's the official MPN for the OH55A-S?
LH55OHAOSGBXGO. The OH55A-S is the 55-inch member of Samsung's OHA-S Series — the current-generation all-in-one outdoor signage with Magic Protection Glass and hidden-fan ventilation. The 'S' suffix designates the all-in-one weatherproof cabinet variant.
Does the Magic Protection Glass replace anti-glare film?
Yes — Magic Protection Glass is Samsung's bonded anti-reflection treatment integrated into the panel face. No aftermarket film required, and the bonded surface is more durable than retrofit anti-glare layers (which can bubble or peel under direct sun and humidity).
Can the OH55A-S survive coastal salt-fog environments?
Outdoor commercial signage handles light coastal exposure with the standard cabinet. For severe coastal installs (within 200m of saltwater, exposed to salt-fog) consult with us at quote stage — Samsung publishes additional install guidance and may require specific mount finishes to maintain warranty coverage.
How is the OH55A-S different from the OH46B?
The OH55A-S is the 55-inch all-in-one with Magic Protection Glass + hidden-fan ventilation — built for stadium concourses, EV charging stations, and large drive-thru lanes. The OH46B (LH46OHBESGBXGO) is the 46-inch IP56/IK10 sealed-cabinet model — vandal-resistant, ideal for transit platforms and sidewalk-adjacent installs.
Is shipping included?
Yes. Free shipping on every order. Outdoor units ship LTL freight on a single crate (heavier than indoor due to weatherproof cabinet — strongly recommend liftgate at quote stage). Lead time typically 3 to 5 weeks for outdoor SKUs.
Do you accept purchase orders?
Yes. POs accepted from qualified businesses, government, education, and non-profit accounts. Tax-exempt sales OK with valid documentation. Samsung Authorized Reseller — invoices match your AP system requirements.
Can DisplayDetails handle the install?
Yes. Outdoor installs require licensed electricians (for power tap), structural mounting (for wind load), and weatherproof cable management. We coordinate the full install through our nationwide partner network — same project manager from quote through commissioning.
How does the warranty work for outdoor installs?
Samsung commercial warranty (parts and labor, Samsung commercial channel). Outdoor installs are explicitly covered for weather-related component failure as long as the cabinet seal is intact and the install meets Samsung's wind-load and clearance specifications. DisplayDetails handles warranty registration at fulfillment.
Compatible accessories
- Outdoor pole / wall mounts (UL-listed, wind-load rated): Chief Outdoor Wall Mount Series, Peerless-AV DST665-OB, Samsung Outdoor Mount Kit
- Weatherproof signal extenders: Atlona AT-HDR-EX-100CEA (HDBaseT), BrightSign extender for runs over 100 ft
- Remote management / CMS: Samsung VXT (cloud, native), Samsung MagicINFO Server (on-prem), Carousel Cloud, Rise Vision (all support outdoor scheduling + brightness automation)
- Outdoor enclosure accessories: NEMA 4-rated power supply boxes, pole-mount kit with cable management chase
For the official Samsung datasheet, current dimensions, full port list, and warranty terms see the Samsung OH55A-S product page (model LH55OHAOSGBXGO).
-
POs accepted For qualified business buyers
-
Tax-exempt sales Resale & non-profit certificates honored
-
W-9 on request Vendor-onboarding ready
-
Free shipping On all orders, US-wide
-
1-hour quote response Mon–Fri, 9am–6pm ET
Buying 5 or more? Get a custom quote in 1 business hour.
Volume pricing for projects of any size — POs accepted, tax-exempt sales supported, W-9 on request. Free shipping on every order.
Loading specifications…
MPN · LH55OHAOSGBXGO
Samsung OH55A-S — 55" OHA-S Series All-In-One Outdoor Display, >3,500 Nit UL-Verified
Samsung's OH55A-S is the 55-inch all-in-one outdoor commercial display from the current OHA-S Series — UL-verified for outdoor visibility above 3,500 nits, with Magic Protection Glass anti-reflection bonded to the panel face and a hidden internal fan system that prevents humidity buildup without exposing intake or exhaust to the elements. Engineered for drive-thru menu lanes, gas station forecourts, transit hubs, stadium concourses, EV charging stations, and exterior wayfinding — wherever the panel has to survive direct weather and stay sharp in stadium-bowl sun.
>3,500 Nit UL-Verified
IP56 All-In-One
Magic Protection Glass
Hidden Fan Ventilation
24/7 Outdoor Duty
Samsung Warranty
Features that matter for the Samsung OH55A-S
>3,500 Nits — UL-Verified Outdoor Visibility
Third-party UL-verified, not just spec-sheet brightness. Stays readable in stadium-bowl sun, drive-thru lanes at noon, and reflective-canopy gas station forecourts.
IP56 All-In-One Weatherproof Cabinet
Single-piece sealed outdoor enclosure — no separate housing required. Rated against high-pressure water jets, dust, snow, and humidity.
Magic Protection Glass Anti-Reflection
Bonded anti-reflection treatment integrated into the panel face. More durable than retrofit anti-glare film, which can bubble or peel under direct sun and humidity.
Hidden Fan Ventilation
Humidity-prevention airflow without exposed intake/exhaust ports — the difference between standard and coastal-tolerant outdoor signage.
Heat-Resistant Outdoor Design
Engineered for full-sun, high-ambient-temperature, and humid coastal climates. Auto brightness sensor adapts to daylight and night-time levels.
24/7 Outdoor Duty + Samsung VXT
Always-on capable. Samsung VXT cloud CMS for fleet-level content scheduling, brightness automation, and uptime monitoring.
Spec snapshot
Screen Size55 inches
Resolution1,920 × 1,080 (Full HD)
Brightness>3,500 cd/m² (UL-verified)
Weather SealingIP56 all-in-one
Anti-ReflectionMagic Protection Glass
VentilationHidden internal fan
Operating Hours24 hrs/day, 7 days/wk
Auto BrightnessSensor-based
CMSSamsung VXT / MagicINFO
CabinetAll-in-one outdoor (no separate housing)
Full Spec Sheet — Samsung OH55A-S
Display
Screen Size55 inches
Panel TypeS-PVA LED (commercial outdoor)
Resolution1,920 × 1,080 (Full HD)
Aspect Ratio16:9
Brightness>3,500 cd/m² (UL-verified outdoor)
Contrast Ratio4000:1 (typ.)
Viewing Angle178° / 178° (H/V)
Anti-ReflectionMagic Protection Glass (bonded)
Auto BrightnessSensor-based daylight/night adjustment
Operating Hours24 hrs/day, 7 days/wk
OrientationLandscape only
Outdoor Protection
Weather SealingIP56 all-in-one sealed cabinet
Front GlassMagic Protection Glass — bonded anti-reflection
Cabinet ConstructionAll-in-one weatherproof — no separate housing required
Heat ManagementHidden internal fan ventilation (humidity-prevention airflow without exposed intake/exhaust)
Coastal ToleranceStandard cabinet handles light coastal exposure; severe salt-fog environments may require additional install guidance
Connectivity
HDMI2 (HDMI 2.0)
DisplayPort1 (DP 1.2)
USB1 (USB 2.0)
AudioAudio In, Audio Out, RJ45
RS232CYes (in/out)
CMS CompatibilitySamsung VXT, MagicINFO Server, BrightSign, Carousel Cloud
Physical
Dimensions (W × H × D)1,300 × 776 × 145 mm (51.2" × 30.6" × 5.7") approx.
Weight44.0 kg (97.0 lbs) approx.
VESA Mount400 × 400 mm (use UL-listed wind-load rated outdoor mount)
Cabinet ColorBlack
Power & Environment
Power SupplyAC 100–240V, 50/60Hz
Power Consumption (typ.)395W
Power Consumption (max)550W
Operating Temperature-30°C to 50°C (-22°F to 122°F)
Operating Humidity10% to 100% (sealed cabinet)
Storage Temperature-30°C to 60°C
Certifications & Warranty
Brightness CertificationUL-verified outdoor signage brightness
Safety / EMCFCC, UL
Commercial Warranty3 Year Samsung Commercial (outdoor — parts & labor, sealed cabinet must remain intact)
Wind Load / MountInstall must meet Samsung's outdoor wind-load and clearance specs
Where the OH55A-S fits
- Quick-service drive-thru lanes — outdoor menu boards with daypart-able content and POS-tied dynamic pricing.
- Gas station forecourts & convenience stores — fuel pricing, fountain promos, lottery results. Magic Protection Glass keeps content readable through canopy reflections.
- EV charging stations — sponsor advertising while drivers wait. Emerging high-margin advertising surface.
- Transit hubs (bus shelter, train platform, ferry terminal) — schedule info, sponsor inventory, weather alerts.
- Stadium concourses & outdoor concession stands — menu, beer wall, sponsor inventory readable in stadium sun.
- Building-mounted directory or wayfinding (covered exterior) — campus, hospital, government complex, corporate park exterior signage.
- Auto dealership outdoor lots — vehicle spotlights, financing offers, service department promotions.
Procurement FAQ
What's the official MPN for the OH55A-S?
LH55OHAOSGBXGO. The OH55A-S is the 55-inch member of Samsung's OHA-S Series — the current-generation all-in-one outdoor signage with Magic Protection Glass and hidden-fan ventilation. The 'S' suffix designates the all-in-one weatherproof cabinet variant.
Does the Magic Protection Glass replace anti-glare film?
Yes — Magic Protection Glass is Samsung's bonded anti-reflection treatment integrated into the panel face. No aftermarket film required, and the bonded surface is more durable than retrofit anti-glare layers (which can bubble or peel under direct sun and humidity).
Can the OH55A-S survive coastal salt-fog environments?
Outdoor commercial signage handles light coastal exposure with the standard cabinet. For severe coastal installs (within 200m of saltwater, exposed to salt-fog) consult with us at quote stage — Samsung publishes additional install guidance and may require specific mount finishes to maintain warranty coverage.
How is the OH55A-S different from the OH46B?
The OH55A-S is the 55-inch all-in-one with Magic Protection Glass + hidden-fan ventilation — built for stadium concourses, EV charging stations, and large drive-thru lanes. The OH46B (LH46OHBESGBXGO) is the 46-inch IP56/IK10 sealed-cabinet model — vandal-resistant, ideal for transit platforms and sidewalk-adjacent installs.
Is shipping included?
Yes. Free shipping on every order. Outdoor units ship LTL freight on a single crate (heavier than indoor due to weatherproof cabinet — strongly recommend liftgate at quote stage). Lead time typically 3 to 5 weeks for outdoor SKUs.
Do you accept purchase orders?
Yes. POs accepted from qualified businesses, government, education, and non-profit accounts. Tax-exempt sales OK with valid documentation. Samsung Authorized Reseller — invoices match your AP system requirements.
Can DisplayDetails handle the install?
Yes. Outdoor installs require licensed electricians (for power tap), structural mounting (for wind load), and weatherproof cable management. We coordinate the full install through our nationwide partner network — same project manager from quote through commissioning.
How does the warranty work for outdoor installs?
Samsung commercial warranty (parts and labor, Samsung commercial channel). Outdoor installs are explicitly covered for weather-related component failure as long as the cabinet seal is intact and the install meets Samsung's wind-load and clearance specifications. DisplayDetails handles warranty registration at fulfillment.
Compatible accessories
- Outdoor pole / wall mounts (UL-listed, wind-load rated): Chief Outdoor Wall Mount Series, Peerless-AV DST665-OB, Samsung Outdoor Mount Kit
- Weatherproof signal extenders: Atlona AT-HDR-EX-100CEA (HDBaseT), BrightSign extender for runs over 100 ft
- Remote management / CMS: Samsung VXT (cloud, native), Samsung MagicINFO Server (on-prem), Carousel Cloud, Rise Vision (all support outdoor scheduling + brightness automation)
- Outdoor enclosure accessories: NEMA 4-rated power supply boxes, pole-mount kit with cable management chase
For the official Samsung datasheet, current dimensions, full port list, and warranty terms see the Samsung OH55A-S product page (model LH55OHAOSGBXGO).
