Samsung OH46B — 46" Outdoor Display, IP56/IK10, 3,500 Nit (LH46OHBESGBXGO)
Sale price
$4,499.00
Regular price
$4,724.00
Skip to product information
Samsung OH46B — 46" Outdoor Display, IP56/IK10, 3,500 Nit (LH46OHBESGBXGO)
Sale price
$4,499.00
Regular price
$4,724.00
MPN · LH46OHBESGBXGO
Samsung OH46B — 46" OH Series Outdoor Display, IP56 / IK10, 3,500 Nit UL-Verified
Samsung's OH46B is the 46-inch sealed-cabinet outdoor commercial display engineered for drive-thru menu lanes, gas station forecourts, transit shelters, EV charging stations, and exterior wayfinding. UL-verified 3,500-nit brightness, IP56-sealed against rain and dust, IK10 vandal-resistance, and Magic Protection Glass anti-reflection — built for unsheltered installs where rain, snow, dust, vandalism, and direct sun are all part of the operating envelope. Samsung VXT remote management built in, 24/7 outdoor duty cycle.
3,500 Nit UL-Verified
IP56 Weatherproof
IK10 Vandal-Resistant
Magic Protection Glass
24/7 Outdoor Duty
Samsung Warranty
Features that matter for the Samsung OH46B
3,500 Nits — UL-Verified Outdoor Visibility
Third-party UL-verified for outdoor signage brightness, not just spec-sheet numbers. Readable in direct sun across drive-thru lanes, gas station forecourts, and stadium concourses.
IP56 Weatherproof Cabinet
Sealed against rain, snow, dust, and pressure-washing. The all-in-one outdoor enclosure is built directly into the display — no external housing required.
IK10 Vandal Resistance
Highest-tier impact resistance per IEC 62262 — cabinet and front glass rated to absorb a 20-joule impact. Built for sidewalk-adjacent, school-property, and transit-platform installs where vandalism is a real risk.
Magic Protection Glass Anti-Reflection
Bonded anti-reflection treatment integrated into the panel face — more durable than retrofit anti-glare film (which can bubble or peel under direct sun and humidity).
Built-In Heat & Humidity Management
Auto-cooling and ventilation maintains optimal internal conditions across full-sun, freezing-rain, and humid coastal install environments.
24/7 Outdoor Operation
Commercial-grade reliability for always-on exterior signage. Samsung VXT remote management for fleet-level content scheduling, brightness automation, and uptime monitoring.
Spec snapshot
Screen Size46 inches
Resolution1,920 × 1,080 (Full HD)
Brightness3,500 cd/m² (UL-verified)
Weather SealingIP56
Impact RatingIK10
Anti-ReflectionMagic Protection Glass
Operating Hours24 hrs/day, 7 days/wk
Auto BrightnessSensor-based
Heat ManagementBuilt-in active cooling
CMSSamsung VXT / MagicINFO
Full Spec Sheet — Samsung OH46B
Display
Screen Size46 inches
Panel TypeS-PVA LED (commercial outdoor)
Resolution1,920 × 1,080 (Full HD)
Aspect Ratio16:9
Brightness3,500 cd/m² (UL-verified outdoor)
Contrast Ratio4000:1 (typ.)
Viewing Angle178° / 178° (H/V)
Anti-ReflectionMagic Protection Glass (bonded)
Auto BrightnessSensor-based daylight/night adjustment
Operating Hours24 hrs/day, 7 days/wk
OrientationLandscape only
Outdoor Protection
Weather SealingIP56 (sealed against rain, snow, dust, pressure-wash)
Impact ResistanceIK10 (per IEC 62262 — 20-joule impact)
Front GlassTempered, anti-reflection treated
Cabinet ConstructionSealed all-in-one outdoor cabinet
Heat ManagementBuilt-in active cooling fans
Connectivity
HDMI2 (HDMI 2.0)
DisplayPort1 (DP 1.2)
USB1 (USB 2.0)
AudioAudio In, Audio Out, RJ45
RS232CYes (in/out)
CMS CompatibilitySamsung VXT, MagicINFO Server, BrightSign
Physical
Dimensions (W × H × D)1,103.4 × 660.4 × 132.0 mm (43.4" × 26.0" × 5.2")
Weight31.6 kg (69.7 lbs)
VESA Mount400 × 400 mm (use UL-listed wind-load rated outdoor mount)
Cabinet ColorBlack
Power & Environment
Power SupplyAC 100–240V, 50/60Hz
Power Consumption (typ.)330W
Power Consumption (max)480W
Operating Temperature-30°C to 50°C (-22°F to 122°F)
Operating Humidity10% to 100% (sealed cabinet)
Storage Temperature-30°C to 60°C
Certifications & Warranty
Brightness CertificationUL-verified outdoor signage brightness
Safety / EMCFCC, UL
Commercial Warranty3 Year Samsung Commercial (outdoor — parts & labor, sealed cabinet must remain intact)
Wind Load / MountInstall must meet Samsung's outdoor wind-load and clearance specs
Where the OH46B fits
- Quick-service drive-thru lanes — outdoor menu boards with daypart-able content and POS-tied dynamic pricing.
- Gas station forecourts & convenience stores — fuel pricing, fountain promos, lottery results. Vandal-resistant for public installs.
- EV charging stations — sponsor advertising while drivers wait. Emerging high-margin advertising surface.
- Transit hubs (bus shelter, train platform, ferry terminal) — schedule info, sponsor inventory, weather alerts. IK10 rating purpose-built for transit-platform installs.
- Stadium concourses & outdoor concession stands — menu, beer wall, sponsor inventory readable in stadium sun.
- Exterior wayfinding — campus, hospital, government complex, corporate park exterior signage.
- Outdoor retail / market stalls — covered exterior installs at premium retail centers and food halls.
Procurement FAQ
What's the difference between the OH46B and OH46DX?
The OH46B (LH46OHBESGBXGO) is Samsung's current sealed-cabinet 46-inch outdoor signage with Magic Protection Glass anti-reflection coating. The OH46DX is a separate Samsung outdoor SKU (LH46OHDEBGBXGO). DisplayDetails carries the OH46B as our 46-inch outdoor recommendation. Confirm MPN at quote stage.
What does IP56 + IK10 mean for my install?
IP56 = sealed against high-pressure water jets and dust ingress. IK10 = highest impact-resistance rating in IEC 62262 (20-joule impact resistance, equivalent to a 5kg object dropped from 40cm). Together they make the OH46B viable for unsheltered public installs without an external enclosure.
Does the OH46B need a special mounting bracket?
Yes — outdoor installs require structural-rated mounts (wind-load engineered). Samsung sells outdoor pole-mount and wall-mount kits sized for the OH Series; Chief and Peerless also make UL-listed outdoor brackets. We spec the right mount at quote stage.
Is shipping included?
Yes. Free shipping on every order. Outdoor units ship LTL freight on a single crate (heavier than indoor due to weatherproof cabinet — strongly recommend liftgate at quote stage). Lead time typically 3 to 5 weeks for outdoor SKUs.
Do you accept purchase orders?
Yes. POs accepted from qualified businesses, government, education, and non-profit accounts. Tax-exempt sales OK with valid documentation. Samsung Authorized Reseller — invoices match your AP system requirements.
Can DisplayDetails handle the install?
Yes. Outdoor installs require licensed electricians (for power tap), structural mounting (for wind load), and weatherproof cable management. We coordinate the full install through our nationwide partner network — same project manager from quote through commissioning.
How does the warranty work for outdoor installs?
Samsung commercial warranty (parts and labor, Samsung commercial channel). Outdoor installs are explicitly covered for weather-related component failure as long as the cabinet seal is intact and the install meets Samsung's wind-load and clearance specifications. DisplayDetails handles warranty registration at fulfillment.
Compatible accessories
- Outdoor pole / wall mounts (UL-listed, wind-load rated): Chief Outdoor Wall Mount Series, Peerless-AV DST665-OB, Samsung Outdoor Mount Kit
- Weatherproof signal extenders: Atlona AT-HDR-EX-100CEA (HDBaseT), BrightSign extender for runs over 100 ft
- Remote management / CMS: Samsung VXT (cloud, native), Samsung MagicINFO Server (on-prem), Carousel Cloud, Rise Vision (all support outdoor scheduling + brightness automation)
- Outdoor enclosure accessories: NEMA 4-rated power supply boxes, pole-mount kit with cable management chase
For the official Samsung datasheet, current dimensions, full port list, and warranty terms see the Samsung OH46B product page (model LH46OHBESGBXGO).
-
POs accepted For qualified business buyers
-
Tax-exempt sales Resale & non-profit certificates honored
-
W-9 on request Vendor-onboarding ready
-
Free shipping On all orders, US-wide
-
1-hour quote response Mon–Fri, 9am–6pm ET
Buying 5 or more? Get a custom quote in 1 business hour.
Volume pricing for projects of any size — POs accepted, tax-exempt sales supported, W-9 on request. Free shipping on every order.
Loading specifications…
MPN · LH46OHBESGBXGO
Samsung OH46B — 46" OH Series Outdoor Display, IP56 / IK10, 3,500 Nit UL-Verified
Samsung's OH46B is the 46-inch sealed-cabinet outdoor commercial display engineered for drive-thru menu lanes, gas station forecourts, transit shelters, EV charging stations, and exterior wayfinding. UL-verified 3,500-nit brightness, IP56-sealed against rain and dust, IK10 vandal-resistance, and Magic Protection Glass anti-reflection — built for unsheltered installs where rain, snow, dust, vandalism, and direct sun are all part of the operating envelope. Samsung VXT remote management built in, 24/7 outdoor duty cycle.
3,500 Nit UL-Verified
IP56 Weatherproof
IK10 Vandal-Resistant
Magic Protection Glass
24/7 Outdoor Duty
Samsung Warranty
Features that matter for the Samsung OH46B
3,500 Nits — UL-Verified Outdoor Visibility
Third-party UL-verified for outdoor signage brightness, not just spec-sheet numbers. Readable in direct sun across drive-thru lanes, gas station forecourts, and stadium concourses.
IP56 Weatherproof Cabinet
Sealed against rain, snow, dust, and pressure-washing. The all-in-one outdoor enclosure is built directly into the display — no external housing required.
IK10 Vandal Resistance
Highest-tier impact resistance per IEC 62262 — cabinet and front glass rated to absorb a 20-joule impact. Built for sidewalk-adjacent, school-property, and transit-platform installs where vandalism is a real risk.
Magic Protection Glass Anti-Reflection
Bonded anti-reflection treatment integrated into the panel face — more durable than retrofit anti-glare film (which can bubble or peel under direct sun and humidity).
Built-In Heat & Humidity Management
Auto-cooling and ventilation maintains optimal internal conditions across full-sun, freezing-rain, and humid coastal install environments.
24/7 Outdoor Operation
Commercial-grade reliability for always-on exterior signage. Samsung VXT remote management for fleet-level content scheduling, brightness automation, and uptime monitoring.
Spec snapshot
Screen Size46 inches
Resolution1,920 × 1,080 (Full HD)
Brightness3,500 cd/m² (UL-verified)
Weather SealingIP56
Impact RatingIK10
Anti-ReflectionMagic Protection Glass
Operating Hours24 hrs/day, 7 days/wk
Auto BrightnessSensor-based
Heat ManagementBuilt-in active cooling
CMSSamsung VXT / MagicINFO
Full Spec Sheet — Samsung OH46B
Display
Screen Size46 inches
Panel TypeS-PVA LED (commercial outdoor)
Resolution1,920 × 1,080 (Full HD)
Aspect Ratio16:9
Brightness3,500 cd/m² (UL-verified outdoor)
Contrast Ratio4000:1 (typ.)
Viewing Angle178° / 178° (H/V)
Anti-ReflectionMagic Protection Glass (bonded)
Auto BrightnessSensor-based daylight/night adjustment
Operating Hours24 hrs/day, 7 days/wk
OrientationLandscape only
Outdoor Protection
Weather SealingIP56 (sealed against rain, snow, dust, pressure-wash)
Impact ResistanceIK10 (per IEC 62262 — 20-joule impact)
Front GlassTempered, anti-reflection treated
Cabinet ConstructionSealed all-in-one outdoor cabinet
Heat ManagementBuilt-in active cooling fans
Connectivity
HDMI2 (HDMI 2.0)
DisplayPort1 (DP 1.2)
USB1 (USB 2.0)
AudioAudio In, Audio Out, RJ45
RS232CYes (in/out)
CMS CompatibilitySamsung VXT, MagicINFO Server, BrightSign
Physical
Dimensions (W × H × D)1,103.4 × 660.4 × 132.0 mm (43.4" × 26.0" × 5.2")
Weight31.6 kg (69.7 lbs)
VESA Mount400 × 400 mm (use UL-listed wind-load rated outdoor mount)
Cabinet ColorBlack
Power & Environment
Power SupplyAC 100–240V, 50/60Hz
Power Consumption (typ.)330W
Power Consumption (max)480W
Operating Temperature-30°C to 50°C (-22°F to 122°F)
Operating Humidity10% to 100% (sealed cabinet)
Storage Temperature-30°C to 60°C
Certifications & Warranty
Brightness CertificationUL-verified outdoor signage brightness
Safety / EMCFCC, UL
Commercial Warranty3 Year Samsung Commercial (outdoor — parts & labor, sealed cabinet must remain intact)
Wind Load / MountInstall must meet Samsung's outdoor wind-load and clearance specs
Where the OH46B fits
- Quick-service drive-thru lanes — outdoor menu boards with daypart-able content and POS-tied dynamic pricing.
- Gas station forecourts & convenience stores — fuel pricing, fountain promos, lottery results. Vandal-resistant for public installs.
- EV charging stations — sponsor advertising while drivers wait. Emerging high-margin advertising surface.
- Transit hubs (bus shelter, train platform, ferry terminal) — schedule info, sponsor inventory, weather alerts. IK10 rating purpose-built for transit-platform installs.
- Stadium concourses & outdoor concession stands — menu, beer wall, sponsor inventory readable in stadium sun.
- Exterior wayfinding — campus, hospital, government complex, corporate park exterior signage.
- Outdoor retail / market stalls — covered exterior installs at premium retail centers and food halls.
Procurement FAQ
What's the difference between the OH46B and OH46DX?
The OH46B (LH46OHBESGBXGO) is Samsung's current sealed-cabinet 46-inch outdoor signage with Magic Protection Glass anti-reflection coating. The OH46DX is a separate Samsung outdoor SKU (LH46OHDEBGBXGO). DisplayDetails carries the OH46B as our 46-inch outdoor recommendation. Confirm MPN at quote stage.
What does IP56 + IK10 mean for my install?
IP56 = sealed against high-pressure water jets and dust ingress. IK10 = highest impact-resistance rating in IEC 62262 (20-joule impact resistance, equivalent to a 5kg object dropped from 40cm). Together they make the OH46B viable for unsheltered public installs without an external enclosure.
Does the OH46B need a special mounting bracket?
Yes — outdoor installs require structural-rated mounts (wind-load engineered). Samsung sells outdoor pole-mount and wall-mount kits sized for the OH Series; Chief and Peerless also make UL-listed outdoor brackets. We spec the right mount at quote stage.
Is shipping included?
Yes. Free shipping on every order. Outdoor units ship LTL freight on a single crate (heavier than indoor due to weatherproof cabinet — strongly recommend liftgate at quote stage). Lead time typically 3 to 5 weeks for outdoor SKUs.
Do you accept purchase orders?
Yes. POs accepted from qualified businesses, government, education, and non-profit accounts. Tax-exempt sales OK with valid documentation. Samsung Authorized Reseller — invoices match your AP system requirements.
Can DisplayDetails handle the install?
Yes. Outdoor installs require licensed electricians (for power tap), structural mounting (for wind load), and weatherproof cable management. We coordinate the full install through our nationwide partner network — same project manager from quote through commissioning.
How does the warranty work for outdoor installs?
Samsung commercial warranty (parts and labor, Samsung commercial channel). Outdoor installs are explicitly covered for weather-related component failure as long as the cabinet seal is intact and the install meets Samsung's wind-load and clearance specifications. DisplayDetails handles warranty registration at fulfillment.
Compatible accessories
- Outdoor pole / wall mounts (UL-listed, wind-load rated): Chief Outdoor Wall Mount Series, Peerless-AV DST665-OB, Samsung Outdoor Mount Kit
- Weatherproof signal extenders: Atlona AT-HDR-EX-100CEA (HDBaseT), BrightSign extender for runs over 100 ft
- Remote management / CMS: Samsung VXT (cloud, native), Samsung MagicINFO Server (on-prem), Carousel Cloud, Rise Vision (all support outdoor scheduling + brightness automation)
- Outdoor enclosure accessories: NEMA 4-rated power supply boxes, pole-mount kit with cable management chase
For the official Samsung datasheet, current dimensions, full port list, and warranty terms see the Samsung OH46B product page (model LH46OHBESGBXGO).
